| Product Information | |
| Collection | SPC XL CLICK TILE |
| Size | 470 X 740 X 4 MM + 1MM IXPE ( 10 times ） |
| Wear Layer | 0.3mm |
| Finish | High Gloss ( 90-100 Degree ) |
| Texture | Flat |
| Performance | Test Method | Requirements | Result | |
| General appearance | Openings between elements, (o) | ISO 24337 | o average ≤ 0,15 mm | o average ≤ 0,04 mm |
| o max. ≤ 0,20 mm | o max. ≤ 0,06 mm | |||
| Height difference between connected elements, (h) | ISO 24337 | h average ≤ 0,10 mm | h average ≤ 0,05 mm | |
| h max. ≤ 0,15 mm | h max. ≤ 0,06 mm | |||
| Flatness of the element - in the length, (f l) | ISO 24337 | f l, concave ≤ 0,50 % | f l, concave ≤ 0,00 % | |
| f l, convex ≤ 1,00 % | f l, convex ≤ N/A % | |||
| Flatness of the element - in the width, (f w) | f w, concave ≤ 0,15 % | f w, concave ≤ 0,02 % | ||
f w, convex ≤ 0,20 % | f w, convex ≤ N/A % | |||
| Dimensional stability due to variation of temperature | ISO 23999 | Length average -0.05% | Length average -0.05% | |
| Width average -0.05% | Width average -0.05% | |||
| Curling average 0.10mm | Curling average 0.10mm | |||
| Color fastness | Cycle A1, Method 3 | ISO 105-B02 | N/A | Grade 6 |
| Abrasion resistance | Method A | EN 13329 | ≥ 2000 cycles | >2200 cycles |
| AC3 | ||||
| Method B | EN 15468 | ≥ 7000 cycles | ≥ 7000 cycles | |
| Micro-scratch resistance | Procedure A | EN 16094 | ≤ MSR-A2 | MSR-A1 |
| Procedure B | ≤ MSR-B2 | MSR-A2 | ||
| Impact resistance | Big ball | EN 13329 | ≥ 1800 mm | 1800 mm |
| Effect of a furniture leg | EN 424 | No damage shall be visible, when tested with foot type 0 | No visible damage | |
| Castor chair resistance | EN 425 | 25 000 cycles, No damage | Pass 25000 cycles | |
| Thickness swelling | Length direction | ISO 24336 | ≤ 12 % | 0.04% |
| Width direction | ||||
| Locking strength - long side | ISO 24334 | fl0,2 ≥ 2.0 kN/m | 6.12 | |
| Locking strength - short side | fs0,2 ≥ 3.5 kN/m | 5.69 | ||
| Resistance to staining | group 1 and 2 | EN 438-2 | Grade 5 | Grade 5 |
| group 3 | Grade 4 | Grade 4 | ||
| Additional features | |||
U-Protect - resistant to oil-based marker | PD internal method | N/A | Rating 5 (No change) |
Phthalate content test | EN 14372 | 0.10% | Not detected |
Heavy metal migration | EN 71-3 | Limit 10mg/kg - 100mg/kg | Not detected |
SVHC (Substance of very high concern) | REACH | Report limit 0.05% (whole product) | Not detected |
IIC (Calculated Impact Insulation Class) | ASTM E492-09 | N/A | 54 |
STC (Calculated Sound Transmission Class) | ASTM E90-2009 | N/A | 53 |
Slip resistanc | DIN 51130 | N/A | Rating 10 |
Plant Certification | ISO 14001 | Meets Certification Guildlines | Certified |
Indoor Air Quality | FloorScore | Meets Certification Guildlines | Certified |
